BENINCA BULL17 OMI

400 Vac three-phase gear motor for intensive use with integrated control unit and oil bath lubrication | Oil-immersed bronze gear for high durability and smooth operation | Mechanical parts in an oil bath ensure optimal lubrication and long lifespan | Encoder technology for precise control of gate movement and maximum safety | Integrated control unit with inverter for speed management and soft start/soft stop functions | Heavy-duty design for industrial and commercial sliding gates | Operation guaranteed in extreme conditions thanks to high-torque motor and robust construction | Anti-crushing safety with torque adjustment and obstacle detection

Features:

• Integrated control unit with inverter technology
• Adjustable opening and closing speeds via control unit
• Soft start and soft stop for smooth operation
• Encoder for position control and safety
• Oil bath lubrication for gears and mechanical components
• High-performance bronze gear wheel
• Supports intensive duty cycle
• Adjustable electronic torque control
• Manual release with key in case of power failure
• Optional safety accessories and flashing light connections

Package Contains:

• 1 × BENINCÀ BULL17 OMI Motor

Specifications:

• Maximum gate weight: Up to 1700 kg
• Power supply: 400 Vac three-phase (50–60 Hz)
• Motor supply: 400 Vac three-phase
• Max absorbed current: 2.8 A
• Maximum thrust: 1550 N
• Opening speed: 10.5 m/min (adjustable with inverter)
• Duty cycle: Intensive use
• Protection rating: IP44
• Lubrication: Oil bath
• Operating temperature: -20 °C / +50 °C
• Weight: 25 kg
• Pinion for rack: M4 Z18
